Comar 6 Stick Build or Ladder Frame

Stick Build:

• Square or step cut transom
• Suitable for inclined facades and roof glazing applications, including barrel vaults and high-rise applications
• Unique cleating and bracket arrangements ensure easy & precise fabrication
• Drainage spouts ensure that water clears the facade maintaining year-on-year performance
• Pre-punched pressure plates facilitate quick and precise assembly
• Full selection of clip on sub-cills can be installed on completion of project
• Comprehensive range of tie back brackets ensuring accurate and easy installation for all project applications
• Vision glass or spandrel panels from 3mm to 50mm thick
• Mullion drained
• Sections available to accept Axim transom closers;
• Comar 7 doors can be hung directly from the curtain walling ensuring that slim sightlines are maintained even at ground floor entrance level
• Entrances also utilise Comar 7 anti-finger trap stiles
• To provide opening lights throughout the facade, the full range of Comar 5, 5lt and 5P.i windows can be integrated
• To add feature to the facade a wide range of mullion and transom capping including square, elliptical and bull nose are available
• Designed to CWCT standards & recommendations
• Full range of high deflection load profiles to meet the most demanding facade requirements

Ladder Frame:

• Square cut transoms with transom end pad ensures precision of joint integrity and aesthetic appeal
• Drainage spouts ensure that water clears the facade maintaining year-on-year performance
• Full selection of clip on sub-cills can be installed on completion of project
• Comprehensive range of tie back brackets ensuring accurate and easy installation for all project applications
• Vision glass or spandrel panels from 3mm to 50mm thick
• Mullion drained
• Sections available to accept Axim transom closers
• Comar 7 doors can be hung directly from the curtain walling
• Entrances also utilise Comar 7 anti-finger trap stiles
• To add feature to the facade a wide range of mullion and transom capping including square, elliptical and bull nose are available

Download the brochure here

Comar 6 EFT 50mm
Comar 6 EFT offers architects custom made solutions and design flexibility which delivers curtain walling with 50mm standardised sightlines with options for:

• Four-sided structural silicon glazing
• Two-sided structural silicon glazing with horizontal or vertical capping
• Concealed vents which maintain the slim 50mm sightlines
• Roof glazing which can be pitched, sloped, barrelled or pyramid
• Faceted glazing options

When tested to the latest CWCT standards, the Comar 6 EFT system achieved air permeability 750 pascals, water tightness 750 pascals static, water tightness 600 pascals dynamic, wind resistance 2400 pascals and 3600 pascals safety. The Comar 6 EFT system is available in RAL, Syntha-Pulvin and BS colours.

Download the brochure here

Comar 9P.i High Performance Window Walling
Comar 9P.i High Performance Window, Doors & Framing, offers an truly integrated solution with low U-values and fast-track fabrication & installation. Configured as an 80mm, 100mm, 120mm mitre or ladder frame system, with the options for internal and external glazing options, a range of window configurations, side or top-hung windows and tilt and turn windows this system is truly flexible to meet the demands. The system fully integrates into existing systems with glass & panel thickness up to 45mm. Exceeding the requirements of BS 6375, achieving 600Pa Air, 600Pa Water at 2400Pa Resistance to Wind Load, and security concerns are alleviated with the system conforming to PAS 24:2012.

Download the brochure here

Comar 2 Window Walling
Comar 2 Window Walling was developed in conjunction with Local Authorities to provide a cost effective alternative to low-rise curtain walling. A thermally broken system made up of two-part channel and plate clipped together to create ladder frame. Available in two sizes 45mm x 100mm or 30mm x 100mm, the system can be internally beaded for security, however an externally beaded option is available. With variable angle corners, 4mm – 75mm glazing options and a variety of beads enabling panels and glass of different thickness to be glazed into the same facade, this system is flexible to meet the design needs.
